Control zones simultaneously by grouping them. Follow these steps to group zones:

1 – Go to (A) and Groups (B) to view the Groups screen (C).*

2 – Select the zones that you want to group together. In this example Zones A and B are grouped in Group 1 (F).

3 – Save your settings (E).

4 – Go to the screen title bar (G) and press either of the arrow buttons until “Group 1: AB” appears (G).

5 – Choose a lighting effect (H), and it will be applied to “Group: AB.” If you later make a change to just Zone A, Zone B will stay the same, but Zone A will now be different.

Follow the same steps to create other groups.

There are four groups total (D).

Zones that are assigned Status Pro or Water Temperature functions can not be grouped. Zones that are assigned the Normal function can be grouped (view page 24).
